==== 【Functions and Features】
1. Gap& pressure detection between contacts,Gap≥1.5MM, pressure ≥4g, the error between the judged value and the actual value ≤±0.01MM. The data can be stored;
2. Dispensing machine dispensing needle has preheating and heating insulation function. Preheating temperature range is 40±10°C, automatic monitoring and automatically alarming when abnormality appears;
3. The oven temperature is continuously adjustable within the range of 80~160°C, and the overall temperature difference of the oven is ≤±5°C;
4. The tin dipping time is adjustable from 0 to 5S. The solder paste and rosin liquid are automatically added. The soldering temperature is adjustable from 0 to 550°C. The depth of the soldering pot is controllable by 15MM;
5. The whole line TT≤1.44S, through yield ≥98%;
6. Suction time of complete product test ≤15MS, release time ≤8MS, suction rebound ≤8MS, contact impedance ≤70MΩ, yeild ≥99.5%.
